Description
Benefits
- High operating reliability due to dry, pressure-tight and encapsulated squirrel-cage motor, thermal class F
- Long service life with shaft made of corrosion-resistant stainless steel
- Ease of service with wetted bolts made of stainless steel which are easy to undo even after years of operation
- Trouble-free operation: clogging by coarse particles is prevented by large free passage (free-flow impeller) or by cutter with high mechanical resistance for waste water
- Stationary pump sets easy to install and remove with automatic, bolt-free connection; leakage prevented by elastic sealing elements
Instructions
Technical Specifications
Maximum flow [l/min]141.60 – 666.60
Maximum head [m]8.20 – 21
Input voltage [V]230
Power output – P2 [kW]0.55 – 1.10
Delivery port [“]2, 2 1/2
Maximum immersion depth [m]4.50 – 15
Float switchYES, NO
Maximum current [A]5 – 8.20
Maximum liquid temperature [°C]40
Cable length [m]10
Maximum particle size [mm]7 – 60
Protection [IP]68
Automatic thermal protectionYES
Dry run protectionNO
Speed controlNO
Capacitorintegrated
Pump designvertical
Impeller materialcast iron
Constructionsubmersible
GrinderNO
