Description
The PUMPA inox line CMP/M series of centrifugal surface multistage pumps is designed for demanding industrial applications for pumping clean water not exceeding 70 °C. The parts that come into contact with the pumped liquid are made of high-quality stainless steel. The pumps are suitable for transporting industrial liquids, water treatment, cooling and heating systems, air conditioning systems, boosting pressure in pipelines, and dosing systems.
Main advantages
- Safe and reliable operation thanks to a mechanical shaft seal
- Corrosion protection: parts in contact with the liquid are made of AISI 304 stainless steel, which provides highly resistant protection against corrosion
- Motor: asynchronous, three-phase 3x400V
Application
- Transport of industrial liquids
- Water treatment
- Cooling and heating systems
- Air conditioning systems
- Pressure boosting in pipelines
- Dosing systems
===============================================================
Technical Specifications
Maximum flow [l/min]50 – 600
Maximum head [m]28 – 82
Input voltage [V]3×400
Power output – P2 [kW]0.25 – 4
Suction port [“]1, 5/4, 6/4, 2
Power input – P1 [kW]0.37 – 4.70
Rated flow [l/m]16.60 – 333.30
Rated head [m]19.50 – 64
Delivery port [“]1, 6/4, 2
Maximum suction lift [m]6 – 70
Drinking water certificateNO
Maximum current [A]0.70 – 7.40
Maximum liquid temperature [°C]70
Maximum pressure [bar]10 – 10
Protection [IP]55
Automatic thermal protectionNO
Dry run protectionNO
Off switchNO
Speed controlNO
CapacitorNO
Pump designhorizontal
Impeller materialstainless steel
Constructionmulti-stage
