Description
Centrifugal surface pumps with open impeller PUMPA INOX LINE DWP. The hydraulic part of the pumps is made entirely of high-quality AISI304 stainless steel. The pumps are suitable for pumping slightly contaminated liquids that may contain solid particles up to 19 mm in size.
Main advantages
- Safe and reliable operation – the pump is equipped with a mechanical seal
- Wide range of applications – industrial and domestic applications
- Corrosion protection – parts coming into contact with the liquid are made of AISI 304 stainless steel
- Motor: three-phase 3×230/400V, 50Hz
Application
- Pumping clean and waste water with solid particles up to 19 mm
- Car wash systems
- Industrial washing machines
- Food industry applications
- Swimming pool systems
Solid particle passage
- DWP025-50: 8 mm
- DWP100: 10 mm
- DWP150-400: 19 mm
=======================================================================
Technical Specifications
Maximum flow [l/min]100 – 730
Maximum head [m]10 – 21
Input voltage [V]3×400
Power output – P2 [kW]0.25 – 3
Suction port [“]5/4, 6/4, 2, 2 1/2
Power input – P1 [kW]0.37 – 3.60
Rated flow [l/m]50 – 500
Rated head [m]6.50 – 15
Delivery port [“]1, 6/4, 2
Maximum suction lift [m]5
Drinking water certificateNO
Maximum current [A]0.70 – 5.70
Maximum liquid temperature [°C]70
Maximum pressure [bar]3 – 10
Maximum particle size [mm]8 – 19
Protection [IP]55
Automatic thermal protectionNO
Dry run protectionNO
Off switchNO
Speed controlNO
CapacitorNO
Pump designhorizontal
Impeller materialstainless steel
Constructioncentrifugal
